Paraquadrula Deflandre 1932

Paraquadrula irregularis test. This amoeba is a member of the Arcellinida. The test is round when viewed en-face (the view in these images) and ovoid in the lateral view. The test is composed of secreted rectangular calcite plates cemented into slightly irregular rows. The pseudostome is a broad oval shape (located towards the bottom in in these images). Although the test plates are similar in appearance to those of Quadrulella the plates are siliceous in the latter and the test of Quadrulella is pyriform with a distinct neck. Feeds on algae. From freshwater pond near Boise, Idaho. Oblique illumination.

Nieva de Cameros, La Rioja, Spain

Paraquadrula irregularis - a member of the Arcellinida. The test is round when viewed en-face (the view in these images) and ovoid in the lateral view. The test is composed of secreted rectangular calcite plates cemented into slightly irregular rows. The pseudostome is a broad oval shape (located atowards the bottom in in these images). Although the test plates are similar in appearance to those of Quadrulella the plates are siliceous in the latter and the test of Quadrulella is pyriform with a distinct neck. Feeds on algae. From freshwater pond near Boise, Idaho. Phase contrast.

Villoslada de Cameros, La Rioja, Spain

Paraquadrula builds its scales from calcite, which is birefringent. This is the reason why in DIC (polarized light) they show such different magnitudes. Scale bar indicates 10 µm. Sample from a bog near Reith/Pillersee (Tyrol, Austria). The image was built up using several photomicrographic frames with manual stacking technique. Images were taken using Zeiss Universal with Olympus C7070 CCD camera.Image under Creative Commons License V 3.0 (CC BY-NC-SA).

Urunuela, La Rioja, Spain

Paraquadrula builds its scales from calcite, which is birefringent. This is the reason why in DIC (polarized light) they show such different magnitudes. Scale bar indicates 10 µm. Sample from a bog near Reith/Pillersee (Tyrol, Austria). The image was built up using several photomicrographic frames with manual stacking technique. Images were taken using Zeiss Universal with Olympus C7070 CCD camera.Image under Creative Commons License V 3.0 (CC BY-NC-SA).

Los Cotos, Madrid, Spain

Paraquadrula builds its scales from calcite, which is birefringent. This is the reason why in DIC (polarized light) they show such different magnitudes. Scale bar indicates 10 µm. Sample from a bog near Reith/Pillersee (Tyrol, Austria). The image was built up using several photomicrographic frames with manual stacking technique. Images were taken using Zeiss Universal with Olympus C7070 CCD camera.Image under Creative Commons License V 3.0 (CC BY-NC-SA).

Canada Del Hoyo, Castille la Mancha, Spain

Paraquadrula irregularis The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis Paraquadrula builds its scales from calcite, which is birefringent. This is the reason why in DIC (polarized light) they show such different magnitudes. Scale bar indicates 10 µm. Sample from a bog near Reith/Pillersee (Tyrol, Austria). The image was built up using several photomicrographic frames with manual stacking technique. Images were taken using Zeiss Axioplan with Canon 600D CCD camera.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Bog near Reith/Pillersee (Tyrol, Austria) Latitude: 47.477767 Longitude: 12.337294 Paraquadrula baut seine Schuppen aus Calcit, welches doppelbrechend ist. Dies ist der Grund, warum sie im DIC (polarisiertes Licht) solche unterschiedlichen Helligkeiten haben. Multiebenen-Abbildung, manuell gestapelt. Der Messbalken markiert eine Länge von 10 µm. Probe aus einem Niedermoor bei Reith/Pillersee in Tirol. Mikrotechnik: Zeiss Axioplan, Kamera: Canon 600D. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis Paraquadrula builds its scales from calcite, which is birefringent. This is the reason why in DIC (polarized light) they show such different magnitudes. Scale bar indicates 10 µm. Sample from a bog near Reith/Pillersee (Tyrol, Austria). The image was built up using several photomicrographic frames with manual stacking technique. Images were taken using Zeiss Axioplan with Canon 600D CCD camera.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Bog near Reith/Pillersee (Tyrol, Austria) Latitude: 47.477767 Longitude: 12.337294 Paraquadrula baut seine Schuppen aus Calcit, welches doppelbrechend ist. Dies ist der Grund, warum sie im DIC (polarisiertes Licht) solche unterschiedlichen Helligkeiten haben. Multiebenen-Abbildung, manuell gestapelt. Der Messbalken markiert eine Länge von 10 µm. Probe aus einem Niedermoor bei Reith/Pillersee in Tirol. Mikrotechnik: Zeiss Axioplan, Kamera: Canon 600D. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis Paraquadrula builds its scales from calcite, which is birefringent. This is the reason why in DIC (polarized light) they show such different magnitudes. Scale bar indicates 10 µm. Sample from a bog near Reith/Pillersee (Tyrol, Austria). The image was built up using several photomicrographic frames with manual stacking technique. Images were taken using Zeiss Axioplan with Canon 600D CCD camera.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Bog near Reith/Pillersee (Tyrol, Austria) Latitude: 47.477767 Longitude: 12.337294 Paraquadrula baut seine Schuppen aus Calcit, welches doppelbrechend ist. Dies ist der Grund, warum sie im DIC (polarisiertes Licht) solche unterschiedlichen Helligkeiten haben. Multiebenen-Abbildung, manuell gestapelt. Der Messbalken markiert eine Länge von 10 µm. Probe aus einem Niedermoor bei Reith/Pillersee in Tirol. Mikrotechnik: Zeiss Axioplan, Kamera: Canon 600D. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis Process of binary fission of Paraquadrula irregularis. The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Teilungsvorgang bei Paraquadrula irregularis. Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.

Paraquadrula irregularis The specimen was gathered in a well at Wendelinusplatz in 63820 Elsenfeld (Germany). Copyright Winfried Hölz, Hausen, Germany.Images were taken using Zeiss Axioskop with DSLR.Image under Creative Commons License V 3.0 (CC BY-NC-SA). Place name: Well at Wendelinusplatz in 63820 Elsenfeld (Germany) Latitude: 49.8469263 Longitude: 9.1611486 Probe aus einem Brunnen am Wendelinusplatz in63820 Elsenfeld.Copyright Winfried Hölz, Hausen. Mikrotechnik: Zeiss Axioskop, Kamera: DSLR. Creative Commons License V 3.0 (CC BY-NC-SA). For permission to use of (high-resolution) images please contact postmaster@protisten.de.
